Specifications

Material	Spring steel
For nom. size	22
Nom. size shaft d₁	22
Info	d₄ is the minimum required installation space. During assembly it is essential to not overspread the rings, a maximum spread of 1,01 x d₁ is recommended. For proper installation use pliers with spread limiter or assemble the aid of a cone.
Info	Warning: electroplating of these products may cause hydrogen embrittlement.

Dimensions
